P4.8 Full Color led display screen/display panel with die-casting size of 576x576mm for indoor rental,with high contrast, high definition and good uniformity,
Product Description:
1. Made with black body SMD3535 LEDs, keep wide view angle to 140 degree for horizontal and vertical,high contrast ratio 5000:1
2.. Made with die-casting aluminum,strong profiles with beautiful outlooking and durable,long life time
3. Slim and small cabinet size of 576× 576× 60mm,only 10.5kgs,light weight and portable by one hand
4. Flight case package,convenient to transport and collect,good protection
5. Rental design, easy to install and dismantle without any tools, save much time for installation and maintenance
6. Can be suspend or fixed installation, Seamless splicing,smooth surfacing and perfect vision effect
7. Widely used in public advertising, theatre, live show, live meeting, banquet, stage background,concert, show, event etc.






Product Description:
1. Made with black body SMD3535 LEDs, keep wide view angle to 140 degree for horizontal and vertical,high contrast ratio 5000:1
2.. Made with die-casting aluminum,strong profiles with beautiful outlooking and durable,long life time
3. Slim and small cabinet size of 576× 576× 60mm,only 10.5kgs,light weight and portable by one hand
4. Flight case package,convenient to transport and collect,good protection
5. Rental design, easy to install and dismantle without any tools, save much time for installation and maintenance
6. Can be suspend or fixed installation, Seamless splicing,smooth surfacing and perfect vision effect
7. Widely used in public advertising, theatre, live show, live meeting, banquet, stage background,concert, show, event etc.






P4.8 SMD3528 Indoor full Color LED Screen Specification | ||||||
Pixel pitch | 4.8mm | |||||
Pixel Configuration | 1R1G1B | |||||
LED component | SMD3528 | |||||
Size of module | 288mm*288mm | |||||
Resolution of module | 60x60 | |||||
Size of cabinet | 576mm x 576mm x 65mm | |||||
Resolution of cabinet | 120x120 | |||||
Material of Cabinet | Die-casting Aluminum | |||||
Weight of Cabinet | 10.50KGS | |||||
Brightness | >1500cd/sq.m | |||||
Density | 43042dots/sq.m | |||||
Best viewing angle | 140 /140 | |||||
Pixel Configuration | 1R1G1B | |||||
Best viewing distance | 3-50M | |||||
Maximum power consumption | 1200W/sq.m | |||||
Average power consumption | 640W/sq.m | |||||
Driving method | 1/15 scan | |||||
Control method | Synchronization | |||||
Gray scale | 65536 | |||||
Colors | 256*256*256 | |||||
Color temperature | 3200-9300k | |||||
Uniformity | 97% | |||||
Working voltage | AC220V/110V±10% | |||||
Working temperature | -20ºC~+50ºC±10% | |||||
Working humidity | 10% ~ 90% | |||||
MTBF | 10,000 hours | |||||
Frame frequence | 50/60Hz | |||||
Refresh frequence | >1920Hz | |||||
IP grade | IP31 | |||||
Life Span | 100,000 hours | |||||
Data transafer method | RJ45 | |||||
Pratical standard | CCC TUV-CE ETL etc. | |||||
Effectivce Communication Distance(without relay) | Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M; Single-mode optic fiber: 10KM | |||||
Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. | |||||
Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development |
