| Specification | |
| Pixel pitch | 1.953mm |
| LED encapsulation | 1515 |
| Combination of diode color | 1R1G1B |
| Pixel density | 270421 dots/m2 |
| Module resolution(W×H) | 104×78 dots |
| Module size | 200*150mm |
| Module pixel | 8112 dots/module |
| Scanning mode | 26S |
| Input voltage | DC5V |
| Cabinet size | 400*300mm |
| Module quantity(W*H) | 2*2=4pcs |
| Cabinet resolution | 208*156 dots |
| Max power consumption | 200W/cabinet |
| Ave. power consumption | 50W/cabinet |
| Working voltage | 220V±15% |
| Viewing angle | 120°±10° |
| Storage temperature | -30ºC ~ +60ºC |
| Operating temperature | -20ºC ~ +60ºC |
| Relative humidity | 10%~95% |
| Protection level | IP30 |
| Net weight | 4.8Kg |
| Operating system | WIN 7/ 10 |
| Control method | Synchronous / asynchronous |
| Drive method | 1/26 scanning |
| Refresh rate | ≥2880Hz |
| Frame rate | ≥60Hz |
| Brightness | 600cd/m2 |
| Lifespan | 100,000 hours |
.
