P35mm High Definition Full Color SMD Flexible Led Screen
PRODUCT DESCRIPTION
1. Ultra flexible design make it can be curved freely to achieve creative shapes like arch, circle, wave, customized size available.
2. 70% transparency rate, easy for stage light,fog, lasers go through the screen to create superb visual effect
3. Fast inter-panel locks make it quick and easy to set up and dismantle large-scaled screen, no tools required.
4. Quick hanging up by using the following two pieces of connector
5. LED strips can be taken out to satisfy various creative ideas.
6. Head and tail of the panel, with waterproof connectors
SPECIFICATION
PRODUCT PROCESS
CERTIFICATE
| optical | Pixel Pitch (Pixel Pitch Can Be Customized) | mm | 35mm |
| LED Type | - | SMD3535 | |
| Dot Size(L*W) | mm | 18*18*10.4 | |
| Brightness | nit | 2000 | |
| Panel Resolution (W*H) | pixels | 8*128 | |
| Pixel Density | pixel/m² | 816 | |
| LED Quantity/ Pixel | pixel | 1 | |
| Viewing Angle | degree | H/V140° | |
| Color Depth | bit | 16 bit | |
| Refresh Rate | HZ | 2000 | |
| Electrical | Max Power Consumption | w/sqm | 370 |
| Ave Power Consumption | w/sqm | 180 | |
| Main Power Source | AC/V | AC 100-240V | |
| Input Voltage | DC | 15 | |
| Mechanical | IP Rating | - | IP66 |
| Panel Weight | kg/sqm | 11 | |
| Weight Per Tile | IB/sqm | 24.27 | |
| Life Time | hours | 100,000 | |
| Certification | - | CE,ROHS | |
| Working Temperature | ºC | -20ºC~+45ºC | |
| Humidity | - | 10~90%RH | |
| Control | Control System | - | DVI synchronous |
