P4mm Full Color SMD Wall Mount LED Video Wall LED Display
PRODUCT DESCRIPTION
All modules,powder supplies and receiving cards can be maintained from front.
solution for long-distance and long-time displaying applications.
SPECIFICATION
PRODUCT PROCESS
CERTIFICATE
PRODUCT DESCRIPTION
1. magnetic design ,easy front and black maintenance available
Maintenance tool can play out any module from any place on the screen within 3 seconds. All modules,powder supplies and receiving cards can be maintained from front.
2. wide viewing angle , can be used for more indoor application
Both vertical and horizontal viewing angles can be reached 140 degrees,making it the best solution for long-distance and long-time displaying applications.
3. Standard module design
Same module size for three different Pixel pitches,customers can change modules to ensure different Pixel pitches,thus reducing investment costs.Standard module design enable fast installation and low costs.| OPTICAL | Pixel Pitch | mm | P4 |
| LED No. Per Pixel | pcs/pixel | 1 | |
| Brightness(Adjustment) | cd/m² | 1000 | |
| Cabinet Resolution | dots | 180*180 | |
| Pixel Density | dots/sqm | 62,500 | |
| Viewing Angle(H/V) | degree | H140/ V140 | |
| Color Depth/Number | bit | 14bit | |
| Grey Scale | - | 14bit | |
| ELECTRICAL | Frame Frequency | Hz/s | ≥60 |
| Refresh Rate | Hz | 960 | |
| Max Power Consumption | W/m² | 700 | |
| Ave Power Consumption | W/m² | 255 | |
| Working Voltage | AC | AC110-220 V | |
| Drive Voltage | DC | 5V | |
| Working Temperature | ºC | 0-40 | |
| Humidity | - | 10%-90% | |
| MECHANICAL | Frame Material | - | Aluminum |
| Net Weight | kg/pcs | 22 | |
| Weight Per Tile | lbs | 48.54 | |
| Cabinet Size | mm | 720*720 | |
| Optimum Viewing Distance | m | 4-12m | |
| IP Rating(Front/Rear) | - | IP40/IP21 | |
| Lifetime | hours | 100,000 | |
| Application | - | Indoor |
