The Billboard Led display screen now are widely applied in media advertising, transportation,traffic information distribution of station, quay and airport, conference, shopping mall and so on.
Outdoor Fixed Billboard Advertising Column Type Screen LED Display Features
* Standard cabinet size of 1024*768 mm,easy for assemble
* Die-casting aluminum design, lightweight for installing ,save labor cost.
* New mask design makes LED light almost zero reflection, which ensures the
screen displaying effect;
* High refresh rate and high gray depth,Unique color calibration process,beautiful
natural picture
* Dust-proof and Waterproof of IP65,with -20°C - 60°C working temperature for
outdoor display, adapted to the harsh environment.
* The viewing angle is up to 140 of horizontal and vertical, the image won't be out of
shape or color cast between the range.
* Fanless design, silent when operation,excellent thermal design and cooling
performance
Outdoor Fixed Billboard Advertising Column Type Screen LED Display Specification
Outdoor LED Screen Specification:
| BOF-4 | BOF-6 | BOF-8 | BOF-10 | |
| Physical Pitch | 4.81mm | 6.67mm | 8mm | 10mm |
| Pixel Configutation | SMD2727 | SMD2727 | SMD3535 | SMD3535 |
| Pixel Density | 43,264 pixels/sqm | 22,500 pixels/sqm | 15,625 pixels/sqm | 10,000 pixels/sqm |
| Module Dimention (W*H)(mm) | 250*250 | 320*320 | 256*256 | 320*320 |
| Panel Dimention(mm) | 1000*1000*150 | 1280*960*150 | 1280*768*150 | 1280*960*150 |
| Physical Resolution of Module(W*H) | 52*52 | 48*48 | 32*32 | 32*32 |
| Physical Resolution of Panel(W*H) | 208*208 | 192*144 | 160*96 | 128*96 |
| Panel Material | Steel/Aluminum | Steel/Aluminum | Steel/Aluminum | Steel/Aluminum |
| Weight(kg/sqm) | 65/45 | 65/45 | 65/45 | 65/45 |
| Processing | 16 bit | 16 bit | 16 bit | 16 bit |
| Contrast Ratio | 2,000:1 | 2,000:1 | 2,000:1 | 2,000:1 |
| Average Power Consumption | 360W/panel | 360W/panel | 360W/panel | 360W/panel |
| Max Power Consumption | 900W/panel | 900W/panel | 900W/panel | 900W/panel |
| Brightness | >6,500nits | >6,500nits | >6,500nits | >6,500nits |
| Refresh Rate | >1,920Hz | >1,920Hz | >1,920Hz | >1,920Hz |
| Vertical Viewing Angle | 160° | 160° | 160° | 160° |
| Horizontal Viewing Angle | 140° | 140° | 140° | 140° |
| Servicing | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
| IP Rating(Front/Rear) | IP65/IP54 | IP65/IP54 | IP65/IP54 | IP65/IP54 |
Advantages
* Competitive Price: Orders directly from manufacturer to reduce intermediate expenditure, buy high quality sign products with more reasonable price
* First-class Quality: We provide you with high quality signs produced by our experienced technicians which using high quality raw materials
* Strict Leading Time: Depending on the type and quantity of ordered signs, we generally need only 4 to 15 days to complete the production
* OEM service offered, Customized service offered, Design service offered
* Competitive price, Short delivery, Timely transportation, Installation instruction
* Long time cooperate with signs company, construction company, design company, advertising company, chain shops, distributors, hotels, shopping malls and etc.
Tips
* Payment: We accept the L/C, T/T, Western Union.
* Shipment: We will ship within 30 working days after you placed the order, but the specific delivered time will be affected by the shipping company and shipping details.
* Package: We usually pack the product in a wooden box or flight case.
