indoor LED digital signage
LED poster display
| No | Item | Description | |||||||
| 1 | Product Name | P2.5 Full Color LED Poster Display | |||||||
| 2 | Model No | LEDPoster-P2.5 | |||||||
| 3 | Physical Pixel Pitch | 2.5 mm | |||||||
| 4 | Pixel Type | Real Pixel(1R1G1B) | |||||||
| 5 | Module Size | 320mmx 160mm | |||||||
| 6 | Cabinet Size | 1920*640mm | |||||||
| 7 | Module numbers per cabinet | 12pcsx 2pcs=24pcs | |||||||
| 12 | The size of led poster | 200*72cm | |||||||
| 13 | Total Pixels | 196608pixels | |||||||
| 3.Parameter Description | |||||||||
| Specifictions | |||||||||
| LED Lamps | Type | SMD (High Brightness LEDs) | |||||||
| LED Standard | Real Pixel(1R1G1B) | ||||||||
| Red Wavelength | 625-630nm | ||||||||
| Green Wavelength | 515-530nm | ||||||||
| Blue Wavelength | 465-475nm | ||||||||
| LED Module | Pixel Pitch | 2.5mm | |||||||
| Module Size | 320mmx160mm | ||||||||
| Module Resolution | 128pixelsx64pixels | ||||||||
| LED cabinet | Cabinets Material | die casting aluminum rental Cabinet | |||||||
| Complete Size | 200*72cm | ||||||||
| Cabinet Resolution | 768pixelsx256pixels | ||||||||
| LED Display | Pixel Density | 160000pixels/sq.m | |||||||
| Display Color | 16.7million | ||||||||
| Viewing Angle | 120°(Horizontal),120°(Vertical) | ||||||||
| Max Power Consumption | 1000 w/sq.m | ||||||||
| Average Power Consumption | 300 w/sq.m | ||||||||
| Weight | about 38kg/piece | ||||||||
| Refresh rate | 480-960HZ | ||||||||
| Input Voltage | AC220V/50H or AC110V/60H | ||||||||
| Output Voltage | DC5V,40A | ||||||||
| Grey Scale Levels | R(256) G(256) B(256) | ||||||||
| Display Colors | 1.67 Billion | ||||||||
| MTBF | 5,000 hours | ||||||||
| Life-span | 100,000 hours | ||||||||
| Failure percentage of leds | less than 0.0003 | ||||||||
| Working Temperature | -25ºC~65ºC | ||||||||
| Working Humidity | 10%~99% | ||||||||
| Control System | Control method | Asynchronization | |||||||
| Control System | 3g,/WIFI Control System (sender,receiver,software) | ||||||||
| Software | LED Studio | ||||||||
| Input Signal | MPG/MPEG/MPV/MPA/AVI/VCD/SWF/RM/RA/RM/ASF/BMP /GIF/PCX/TXT/DOC.etc | ||||||||
| PC Operating system | Microsoft Windows 7, 98, 2000, XP and Vista | ||||||||
