Large Size Big 55" Flex OLED / OLED Flexible Panel / Flexible Display / Flexible Screen
Large Size Big 55" Flex OLED / OLED Flexible Panel / Flexible Display / Flexible Screen
| Parameter Chart of Android OS configuration | ||
| Main Specification | Function Version | Double-Sided Android Operating System with Wifi Network+Cable Network and , LG A+ grade Organic Light-Emitting Diode Display panel and, Full HD 1920*1080 2K, wooden box packing |
| Display Size | 55 inches | |
| Packing Material | Veneer Wooden Box (Aluminium Box is optional) | |
| Power Supply | Wide range power input : 110-240V/50HZ/60HZ workable in every country all around the world | |
| Power Comsuption | 38W | |
| Material | (Floor Stand Tpye ) Body : Fully High-tempered Glass Base : Coat Painting Strong Steel (Ceiling Type) Fully High-tempered Glass | |
| Color | (Floor Stand Tpye) Body : Transparent Base :Black/White/Silver (Ceiling Type) Transparent | |
| Dimensions | (Floor Stand Tpye) Display Section: 700mm*10mm for Double Sided totally Base: 700mm*400mm , The total height:1726mm | |
| Gross weight | 30KGS | |
| Operating temperature | -20 ~85ºC | |
| Certificate | CE /ROHS | |
| Mainboard Specification | Mainboard | Gold-coating 10-layer Industrial High Class Micro ATX Form Factor; All Solid Capacitor design ; High Density Glass Fabric PCB |
| Operating System | Android OS 6.1 | |
| CPU | Britain Cortex-A7 Octa-core(8-core) 2.0Ghz | |
| GPU | PowerVR SGX544 | |
| RAM | LPDDR3 1G | |
| Storage | EMMC 8G Byte | |
| Cable Network Connectivity | YES | |
| WIFI connectivity | YES | |
| 4G Network Connectivity | Optional | |
| Bluetooth | N/A | |
| In/Out Interface | 1xUSB 3.0 , copy speed reach to 16M/S; 1xHDMI 2.0 support 4K input; 1xRJ45 Cable Network port | |
| Speaker Power | 2×5W (8Ω) | |
| Color system | PAL/NTSC/SECAM | |
| Video Format | MP4(AVI:DIVX/XVID),MPG2(DVD: VOB/MPG2),MPEG1(VCD:DAT/MPG1),WMV,MP3,MPG,TRP,TP,M2TS,TS,RM,RMVB,MKV, DIVX,ASF,FLV,...etc. support all of the format of video | |
| Audio Format | MP3..etc. all of the format of audio | |
| Image Format | JPG,JPEG,BMP,PNG,GIF...etc, support all of the format of image | |
| OSD Display Language | English/Русский/France/Español/Italian/Português/Japanese/Korean/Hebrew...any all other language | |
| Operating System Language | English/Русский/France/Español/Italian/Português/Japanese/Korean/Hebrew...any all other language | |
| Panel Specification | Panel Brand | LG / SAMSUNG Original A+Grade Organic Light-Emitting Diode Display, without any light spot or black spot and Full Viewing Angle |
| Panel Type | Organic Light-Emitting Diode Display(AM-OLED) | |
| Pixel Format | RGB Vertical Stripe | |
| Resolution | Full HD 1920*1080 2K | |
| Display color | 16.7 Millinium(16.7M/1.07B (8-bit / 8-bit + Hi-FRC) | |
| Display Size | 1209.6 × 680.4 mm (H×V) | |
| Surface Treatment | Hard coating (2H), Reflection 1.0% (Typ.) | |
| Pixel Pitch(mm) | 0.630×0.630 mm (H×V) | |
| Brightness (nits) | 470cd/m2 | |
| Contrast | 15000:1 | |
| Visual angle | Full View 178/178 degreee | |
| White Coordinate | Wx:0.285; Wy:0.294 | |
| Color Gamut | 83% NTSC (CIE1931) | |
| White Uniformity | 1.43 (Max.)(9 points) | |
| Response time | 1ms (Typ.)(G to G); 8 (Typ.)(MPRT) | |
| Life(hrs) | >70,000(hrs) | |
| Parameter Chart of Windows OS Configuration | ||
| Main Specification | Function Version | Double-Sided Android Operating System with Wifi Network+Cable Network and , LG A+ grade Organic Light-Emitting Diode Display panel and, Full HD 1920*1080 2K, wooden box packing |
| Display Size | 55 inches | |
| Packing Material | Veneer Wooden Box (Aluminium Box is optional) | |
| Power Supply | Wide range power input : 110-240V/50HZ/60HZ workable in every country all around the world | |
| Power Comsuption | 38W | |
| Material | (Floor Stand Tpye ) Body : Fully High-tempered Glass Base : Coat Painting Strong Steel (Ceiling Type) Fully High-tempered Glass | |
| Color | (Floor Stand Tpye) Body : Transparent Base :Black/White/Silver (Ceiling Type) Transparent | |
| Dimensions | (Floor Stand Tpye) Display Section: 700mm*10mm for Double Sided totally Base: 700mm*400mm , The total height:1726mm | |
| Gross weight | 30KGS | |
| Operating temperature | -20 ~85ºC | |
| Certificate | CE /ROHS | |
| Mainboard Specification | Motherboard | Intel™ Chipset ;Industrial High Class Micro ATX Form Factor; All Solid Capacitor design ; High Density Glass Fabric PCB ; Support Intel™ Rapid Start Technology and Smart Connect Technology,10 layer gold-coating Mother board. |
| CPU | Intel™ J1900 2.0Ghz(Maximum 2.4G) with integrated Graphics Visuals; (Intel™ i3/i5/i7/i9 is optional) | |
| Operating System | Windows 7/Windows 10 | |
| In/Out Interface Port | 2xUSB3.0,2xUSB2.0,1xHDMI,1xRJ45 Cable Network Port,1xVGA,Audio output, Microphone input | |
| RAM | Brand new Kingston™ or ADATA™ Dual Channel DDR3-1600 Memory Technology 4G (8G/16G is optional) | |
| ROM(Memory) | ADATA™/Kingston™ /Micron/Sandisk/Kingspeed High Speed Solid State Disk 60/64G (128G/256G/1TB is optional) | |
| WIFI Network | Included Embedded (Realtek 8111E ) | |
| 3G/4G Network | Optional | |
| Speaker | High Quality HD | |
| Speaker Power | 2×10W (8Ω) | |
| Color system | PAL/NTSC/SECAM | |
| Video Format | MP4(AVI:DIVX/XVID),MPG2(DVD: VOB/MPG2),MPEG1(VCD:DAT/MPG1),WMV,MP3,MPG,TRP,TP,M2TS,TS,RM,RMVB,MKV, DIVX,ASF,FLV,...etc. support all of the format of video | |
| Audio Format | MP3..etc. all of the format of audio | |
| Image Format | JPG,JPEG,BMP,PNG,GIF...etc, support all of the format of image | |
| OSD Panel Language | English/Русский/France/Español/Italian/Português/Japanese/Korean/Hebrew...any all other language | |
| Panel Specification | Panel Brand | LG / SAMSUNG Original A+Grade Organic Light-Emitting Diode Display, without any light spot or black spot and Full Viewing Angle |
| Panel Type | Organic Light-Emitting Diode Display(AM-OLED) | |
| Pixel Format | RGB Vertical Stripe | |
| Resolution | Full HD 1920*1080 2K | |
| Display color | 16.7 Millinium(16.7M/1.07B (8-bit / 8-bit + Hi-FRC) | |
| Display Size | 1209.6 × 680.4 mm (H×V) | |
| Surface Treatment | Hard coating (2H), Reflection 1.0% (Typ.) | |
| Pixel Pitch(mm) | 0.630×0.630 mm (H×V) | |
| Brightness (nits) | 470cd/m2 | |
| Contrast | 15000:1 | |
| Visual angle | Full View 178/178 degreee | |
| White Coordinate | Wx:0.285; Wy:0.294 | |
| Color Gamut | 83% NTSC (CIE1931) | |
| White Uniformity | 1.43 (Max.)(9 points) | |
| Response time | 1ms (Typ.)(G to G); 8 (Typ.)(MPRT) | |
| Life(hrs) | >70,000(hrs) | |
