LED display,also called led screen, led video wall, or led sign, with its unique advantages,has gradually replaced the traditional billboards, light boxes,etc. LED display advertising has become a new force in the media industry.
Traditional advertising can only show pictures, But LED display/led video wall/led screen can perfect combine text, pictures, video, and sound with high resolution,high brightness and full color! LED display Advertising screen can easily attract the attention of pedestrians,and also are easy to remember,which can generate greater advertising effectiveness.
Led display screen now are widely applied in media advertising, transportantion,Security
Functions and advantages
One: slim and light , front maintenance, zero maintenance, zero noise.
Two: high density , high contrast, high brightness , high ash and high brush.
Three: high precision, seamless stitching, wide viewing angle, low power Consumption, high life, the picture is real natural.
Four: replace LED mosaic wall and DLP projection splicing products, for customers have listened to information dissemination, brand advertising effects, etc. Aspect of high quality services.
Five: applied to monitor the command, advertising, television, senior Frequency conference, cinema, shopping malls, hotels, monopoly and other venues.
Packaging Details
1.module package:40 pcs per Cartons. Cartons Size:430*385*350mm. Weight: 22.1kg/Cartons
2.plywood package
3.flight case package
Port
Xiamen
Lead Time :
7-14days for modules,15-20 days for cabinets
China manufacture outdoor high performance electronic P10/P16/P20 LED display screen
Module | Pixel Pitch | 3.908 mm | Pixel Density | 65536 Dots/ square meters | ||
Configuration | 1R1G1B | Resolution | 64*64=4096 Dots | |||
Size (Width*height*Depth) | 250*250*17mm | Net Weight | 0.55kg±0.01kg | |||
Structure | Led and ICs in same PCB | Plastic Kit | Polycarbonatematerial | |||
Input Voltage(DC) | 4.5V | Maximum Current | ≤8 A | |||
Module Power | ≤36W | Driving method | Constant Current 1/16 scan | |||
Cabinet | Cabinet Dimensions(Width*Height*Depth) | 500*500mm | ||||
Pixel Density | 128*128=16384 Dots | |||||
Square Meters | 0.25 square meters | |||||
Cabinet Weight | / | |||||
Power consumption | 144 w (max) | |||||
Power consumption | 48 w (average) | |||||
Screen power consumption | ≤185 0W/square meters | |||||
Display Screen | Brightness | ≥600 cd/square meters | Brightness uniformity | >0.95 | ||
Viewing angle-Horizontal | 140±10 degree | Viewing angle-Vertical | 130±10 degree | |||
Best viewing distance | ≥4 m | Pixel failure | < 0.0003 | |||
Life Span (hours) | ≥100,000 | Operating Humidity | 10%---90%RH | |||
Led Light Loss (working for 3 years) | ≤15% | Operation Temperature | -20 to 50°C | |||
Control System | Gray Scale | 14-16bits | Display Color | 16777216 | ||
Frame frequency | ≥60 frames/sec | Refresh Rate | ≥1920 Hz | |||
Control Mode | Computer-controlled, point-by-point, correspondence, video synchronization | Brightness adjustment | 256 grade manual/automatic | |||
|
| |||||
Input Signal | DVI/VGA, Video (multiple formats) RGBHV, Composite video signal,S-VIDEO YpbPr (HDTV) | |||||
