Application:
1. It's a advanced LED screen which can be easily installed and removed.
2. Indoor commercial advertising billboard, stage, banks, stock exchange centers, theme park, airport, schools, government agencies, exhibition, meeting rooms, cinemas, hotels, and a variety of public facilities and etc.
Product feature:
Specification:
The development ability:
1. The development of the TURBINE series takes us 4 months.
2. The original intention of TURBINE series is to save maintenance time for LED screen rental business.
3. We can provide all the accessories and software for a whole project. Including hanging bars, sending cards, video processor, software, flight case, power box, power cable, data cable, module mask, etc.
4. We are professional in designing and manufacturing high-end rental LED display screen.
We are a trade factory in Shenzhen with 6 years experience. There are professional develop engineers, experienced sales engineers, and skillful workers.
1. If you want to develop a new design LED screen, please contact us. We can help you.
2. If you have a new project/order but don't know how to process it, please contact us. We can help provide the best solutions/scheme, and guide you.
3. If you are searching for alternative suppliers, please contact us. We are professional.
Factory:
(The pictures below were taken during night, after most of the workers off work)
1. Skillful workers who have worked more than 6 years in our factory.
2. High technology auntomatic machines.
3. Aging test for each module.
1. Production time for 0-200 m² LED screen is about 25 days. (Including aging test).
2. Payment term: T/T, 30% in advance and 70% before shipping.
3. Trade term: FOB Shenzhen, CIF, DDU, DDP.
4. Plywood case or flight case provided.
1. It's a advanced LED screen which can be easily installed and removed.
2. Indoor commercial advertising billboard, stage, banks, stock exchange centers, theme park, airport, schools, government agencies, exhibition, meeting rooms, cinemas, hotels, and a variety of public facilities and etc.
Product feature:
- Highly integrated modular design, easy to replace.
- New lock design, to achieve quick installation; curved connection optional.
- The module power supply box is completely front maintained, saving maintenance time.
- Integrated connection can be quickly inserted and removed, more stable and reliable, and the number of effective insertion and removal is up to 100,000 times.
- High refresh and high gray, rich picture layer, high color saturation, anti-ghost PCB design.
Specification:
| 1 | Model No. | TBI-1.95 |
| 2 | Pixel Pitch (mm) | 1.95 |
| 3 | Module Size (mm) | 250x250x15 |
| 4 | Module Resolution (pixels) | 128x128 |
| 5 | Cabinet Size (mm) | 500x500x91 |
| 6 | Cabinet Resolution (pixels) | 256x256 |
| 7 | Pixel configuration | 1RGB |
| 8 | LED Encapsulation | SMD2020 |
| 9 | Work Voltage (DC) | 5V |
| 10 | Driver Mode (Scan) | 1/32 |
| 11 | Cabinet Weight (kg) | 8.8 |
| 12 | Physical Density (pixels) | 262144 |
| 13 | Brightness (NIT) | 800 |
| 14 | Gray Scale (BIT) | 14 |
| 15 | Contrast Ratio | 3000:1 |
| 16 | Refresh Rate (Hz) | 3840 |
| 17 | Viewing Angle (H/V) | ±140°/±140° |
| 18 | Protection Grade | IP30 |
| 19 | MAX Power Consumption (W/m²) | 424 |
| 20 | Average Power Consumption (W/m²) | 168 |
| 21 | Work Temperature | -20ºC~50ºC |
| 22 | Work Humidity | 10%RH~90%RH |
| 23 | Optimal Viewing Distance | ≥3.5m |
The development ability:
1. The development of the TURBINE series takes us 4 months.
2. The original intention of TURBINE series is to save maintenance time for LED screen rental business.
3. We can provide all the accessories and software for a whole project. Including hanging bars, sending cards, video processor, software, flight case, power box, power cable, data cable, module mask, etc.
4. We are professional in designing and manufacturing high-end rental LED display screen.
We are a trade factory in Shenzhen with 6 years experience. There are professional develop engineers, experienced sales engineers, and skillful workers.
1. If you want to develop a new design LED screen, please contact us. We can help you.
2. If you have a new project/order but don't know how to process it, please contact us. We can help provide the best solutions/scheme, and guide you.
3. If you are searching for alternative suppliers, please contact us. We are professional.
Factory:
(The pictures below were taken during night, after most of the workers off work)
1. Skillful workers who have worked more than 6 years in our factory.
2. High technology auntomatic machines.
3. Aging test for each module.
1. Production time for 0-200 m² LED screen is about 25 days. (Including aging test).
2. Payment term: T/T, 30% in advance and 70% before shipping.
3. Trade term: FOB Shenzhen, CIF, DDU, DDP.
4. Plywood case or flight case provided.
