Hot Sale P6 Outdoor Full Color LED Video Wall For Advertising LED Screen
Overview:
Pixel pitch: 6mm
Refresh rate: ≥1920Hz
Brightness: 6500 CD
Cabinet Size: 576*576mm
Cabinet Weight: 23kg
Pixel density:27777dots/m2
Features:
Product Features: :
Overview:
Pixel pitch: 6mm
Refresh rate: ≥1920Hz
Brightness: 6500 CD
Cabinet Size: 576*576mm
Cabinet Weight: 23kg
Pixel density:27777dots/m2
Features:
- Light Weigh and small structure
- Wide range of sizes
- Fast Installation
- 100 % waterproof, rainproof, and dustproof, IP Grade 65
Cabinet:
- Durable and sturdy aluminum casting cabinet
- IP65 Waterproof
Product name | Outdoor P6 led display | |||
Pixel Pitch(mm) | 6mm | |||
Pixel configuration | 1R1G1B/SMD3535 | |||
Pixel density | 27777dots/sqm | |||
Brightness | ≥6500cd/sqm | |||
Module size(W*H) | 192mm×192mm | |||
Module Resolution (W*H) | 32 dots x 32dots | |||
Module weight | 600g | |||
Cabinet size (W*H) | 576mm×576mm | |||
Drive IC | MBI5124 | |||
Drive mode | 1/8 scan | |||
Viewing Angle(V/H) | 140 ºC | |||
Grey Scale | 65536 degree | |||
Life time | >100,000 Hours(80%) | |||
MTBF | >50,000 Hours | |||
Operating Voltage | AC110V/220V±10% | |||
Screen Power Consumption | Max: 800w/sqm; Average:270w/sqm | |||
Input Power Frequency | 50/60Hz | |||
Operating temperature | -30--60degree | |||
Humidity | 10%-95% | |||
Refresh Rate | ≥1600HZ | |||
Control Method | Synchronized with computer monitor | |||
Color Temperature | 6500K-9500K | |||
LED control system | LINSN,Nova-star,Colorlight is selectable | |||
Control Distance | 100 m (no repeating); Optical fiber transmission: 500m- 15km | |||
Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI | |||
Systems Operating Platform | Windows 7 / windows 8 /8.1 / windows 10 |
