High Definition P3 Video Display Full Color Indoor LED Display board
1.Most of our product use material as follow:
MBI5124IC Driver IC
g-energy power supply
pcb 1.2-1.6mm ,mask and base
2-3 years warranty.
2. If you have interests in buying, pleased send A complete inquiry need to show:
1. led screen panel pixel pitch, if you dont know how to choose, contact us
2. led screen size:length ___m; width___m,or cabinet quantity;
3. use for indoor or outdoor; fixed installation or rental?
4. intallation place pictures will be better;
3.Purchase Suggestion :
If you are looking for led screen that can be used for both outdoor and indoor events, we strongly recommend Outdoor P4.81, current promotion price very good !
If you need for indoor use only, we strongly recommend our best selling indoor P3.91 ,
outdoor products we have P3.91/P4.81/P5/P6/P8/P10 .hot selling have P4.81/P5/ P6 .
indoor products we have P2.5/P3.91/P4.81/P4/P5 .hot selling have P2.5and P3 .
Product descripition:
1.Most of our product use material as follow:
MBI5124IC Driver IC
g-energy power supply
pcb 1.2-1.6mm ,mask and base
2-3 years warranty.
2. If you have interests in buying, pleased send A complete inquiry need to show:
1. led screen panel pixel pitch, if you dont know how to choose, contact us
2. led screen size:length ___m; width___m,or cabinet quantity;
3. use for indoor or outdoor; fixed installation or rental?
4. intallation place pictures will be better;
3.Purchase Suggestion :
If you are looking for led screen that can be used for both outdoor and indoor events, we strongly recommend Outdoor P4.81, current promotion price very good !
If you need for indoor use only, we strongly recommend our best selling indoor P3.91 ,
outdoor products we have P3.91/P4.81/P5/P6/P8/P10 .hot selling have P4.81/P5/ P6 .
indoor products we have P2.5/P3.91/P4.81/P4/P5 .hot selling have P2.5and P3 .
Product descripition:
| NO.: | Product name | P3 high definition rental led display | |||
| 1 | Pixel Pitch(mm) | 3mm | |||
| 2 | Pixel configuration | 1R1G1B/SMD2121 Black lamp | |||
| 3 | Pixel density | 111111dots/m2 | |||
| 4 | Brightness | 1800cd/m2 | |||
| 5 | Module size(W*H) | 192*96mm | |||
| 6 | Module Resolution (W*H) | 64 dots x 32dots | |||
| 7 | Module weight | 600g | |||
| 8 | Cabinet size (W*H) | 576*576mm | |||
| 9 | Drive IC | MBI5124 | |||
| 10 | Drive mode | 1/16 scan | |||
| 11 | Viewing Angle(V/H) | 140 ºC | |||
| 12 | Grey Scale | 65536 degree | |||
| 13 | Life time | >100,000 Hours (50%) | |||
| 14 | MTBF | >50,000 Hours | |||
| 15 | Operating Voltage | AC110V/220V±10% | |||
| 17 | Screen Power Consumption | Max: 760w/m2; Average:260w/m2 | |||
| 18 | Input Power Frequency | 50/60Hz | |||
| 19 | Operating temperature | -30--60ºC | |||
| 20 | Humidity | 10%-95% | |||
| 21 | Refresh Rate | ≥1920HZ | |||
| 22 | Control Method | Synchronized with computer monitor | |||
| 23 | Color Temperature | 6500K-9500K | |||
| 24 | LED control system | LINSN,Nova-star,Colorlight is selectable | |||
| 25 | Control Distance | 100 m (no repeating); Optical fiber transmission: 500m- 15km | |||
| 26 | Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI | |||
| 27 | Systems Operating Platform | Windows 7 / windows 8 /8.1 / windows 10 | |||
