Advertising full color indoor P3 HD LED display board
Product DescriptionAdvantage:
1. High quality LED chip and high anti-static electricity capacity.
2. Large viewing angle and smooth displaying provide excellent visual effect from every angle.
3. The integration of lamp and driving IC,together with with the multi-circuit structure,achievs evenly-distributed current, low power consumption and fast heat dissipation.
4. Ultra high brightness, low attenuation, high reliability and weather ability.
5. High contrast ratio. Adopting black lamps can improve the contrast ratio by 50%.
6. High refresh rate, high gray scale, ghost-canceling, low power consumption, low EMI, anti-creeping, multi-route redundancy backup-supporting, and dot-by-dot-calibration.
Specifications:
| Items | Details | |
| Module Details | Pixel Pitch | 3mm |
| Pixel Configuration | SMD, 3 in 1 | |
| LED Size | 2121 | |
| Module Size | 192mm*192 | |
| Module Resolution | 64*64 dots | |
| Module weight | 0.5kg/module | |
| Cabinet Details | Cabinet Size | (W)576*(H)576*(T)80mm |
| Cabinet Resolution | 192*192 dots | |
| Optical Parameters | Brightness(cd/sqm) | 1000-2500cd/sqms |
| Grey Level | 14-15bit | |
| Viewing angle | 120/140 | |
| Best Viewing Distance | 3~50m | |
| Electrical Parameters | AC Input voltage (V) | 110~240V |
| AC Input frequency (Hz) | 50/60Hz | |
| Power Consumption (W/SQM/H) | Max: 850; Ave:240 | |
| Operation Environment | Storage Temperature (ºC) | -40~+60 (ºC) |
| Operation Temperature (ºC) | -20~+60 (ºC) | |
| Storage Humidity(Rh) | 10%~90% | |
| Protection Level | IP43 | |
| Lifespan | 100000 hours | |
| Installation Type | This high precision indoor LED Display is mainly used for indoor fix installation and rental market, it supports any installation type, hanging with truss, attached on the wall, ect. | |
| Control System | Control Type | Support both sychronous control system and asychronous control system |
After-Sales Service
1) Training after order
After the order is placed, a processional training will be offered, including software use, operate safety, maintain equioment.
2) Installation and debugging
We could send professionals to conduct on site installation and debugging in strict.
3) Warranty
Warranty: 2 years warranty, lifetime maintenance equip with free spare parts. The first 2 years after shipment, we will be responsible for free maintenance if any problem caused by quality itself. While you should take the cost of the freight to us. After 2 years, service is still available, but would charge for labor, material and freight cost that generates.
4) Maintenance
Maintenance principles: response in time, solve problems asap and ensure the use.
Maintenance period: In the maintenance period of the led display body, free of all maintenance charges.
After maintenance period, only charge the material cost and labor cost.
5) service
Your inquiry ralated to our products or price will be replies in 24hours.
OEM&ODM. any your customized lighting we can help you to design and put into product.
Distributorship are offered for your unique design and some our current models.
Protection of your sales area, ideas of design and all your private information.
Top Quality+Reasonable Price+Responsible After Service=Successful&Win
