Features
*1.Through 14-16bit gray scale processing technology to ensure the clarity of image and uniformity of the color.
*2. SMD 3-in-1 technology with high gray scale makes the display have a ultra-wide view & vivid image.
*3. Feature a refresh rate of 1920 HZ which ensure that screen would none of shaking/quick flashing/mosaic problems.
*4. With it ultra thin and light designs, makes it easy to install at any area without any problem.
*5. Through quick locking mechanism, to easy install one cabinet with high accuracy by seconds oneself.
*6. Use by aircraft-grade signal connector t win fast reliable of installation. Not only beautiful appearance but also a real sense of the rapid disassembly.
*7. It has excellent heat dissipation performance with low noise,low power consumption.
Details
| Model | BIR - I-4 |
| Pixel Pitch | 4.81mm |
| Pixel Density | 43,264 px/m² |
| LED Type | SMD2121 |
| LED Configuration | 1R1G1B |
| Module Dimension | 250*250/250*500 |
| Cabinet Dimension | 500*500/500*1000 |
| Cabinet Resolution | 168*168/168*336 |
| Cabinet Weight | 7/13 kg/panel |
| Cabinet Material | die-casting |
| Ingress Protection(front/rear) | IP40/IP21 |
| Brightness | 900-1200nits |
| Contrast ratio | 4000:1 |
| Processing | 14-16bit |
| Colours | 281 trillion |
| Viewing Angle(H/V) | 140°/140° |
| Power Consumption(avg.) | 60/120w/m² |
| Power Consumption(max.) | 110/400w/m² |
| Frame Refresh | ≥ 60Hz |
| Data Refresh Rate | ≥ 1920Hz |
| Power Supply | AC 110/220±10%50~60Hz |
| Temperature(operating/storage) | -10~60°C/-30~60°C |
| Humidity(operating/storage) | 10%~90%RH/10%~85%RH |
| MTBF | ≥1000 Hours |
| Life Span | 100,000 Hours |
| Service | Front/Rear |
| IP rate | IP40 |
Details
Services
1) We can offer customization service for customized products and can provide onsite installation and testing service.
2) We provide 2 years warranty and free repair service for our products sold.
3) We also provide free training to customers' engineer.
4) Regarding the production of products, from raw materials to every process, we have strict production and testing process to ensure that our products under the quality inspection system standards.
5) At the same time, before leaving the factory,we have an aging testing of 72 hours as well as waterproof test of outdoor led display to ensure the high quality of the product.
Tips
1) Payment: We accept the L/C, T/T, Western Union.
2) Shipment: We will ship within 30 working days after you placed the order, but the specific delivered time will be affected by the shipping company and shipping details.
3) Package: We usually pack the product in a wooden box or flight case.
