Main technical parameters:
Item | Parameter | |
LED | GOB (3 in 1) | GOB (3 in 1) |
Pitch | P2.0mm | P2.5mm |
Pixel Density | 250,000 PX | 160,000 PX |
Cabinet Dimensions | 640*480mm | 640*480mm |
Cabinet Resolution | 320*240 PX | 256*192 PX |
Brightness | 400-900 nits | 400-900 nits |
Angle of vision | H140°/ V120° | H140°/ V120° |
Maintenance | Front or Rear | |
Power Con. Per Cabinet | 160 W (Max) 50 W (Average) | 160 W (Max) 50 W (Average) |
IP | IP45 | |
Weight per Cabinet | 10KG | 10KG |
Refresh Rate | 3840HZ | |
Grey Scale | 16 bit | |
Lifetime | 100,000 Hours | |
Connectors | Direct | |
Control system | NovaStar | |
Features:
1. Totally front service design. Led module, power supply and receiver card are front maintenance.
2. Cabinet resolution: easy to match 2K/4K.
3. Led type is GOB not SMD. Waterproof, anti-collision and dust-proof to prolong led displays lifespan.
4. Ultra-thin design, the thickness is less than 90mm.
5. 4K high refresh rate.
GOB advantage:
Installation Stpes:
Our Factory:
Our Certificates:
