| Product Specification |
| General | Panel Brand | Samsung/LG/AUO/Chimei |
| Information | Panel Size | 17-84 Inch Optional |
| | Product Color | Black and silver |
| IR Touch | Touch Max Resolution | 4096×4096 |
| Screen | Transparency | > 90%, Up to 100% |
| Details | Response Speed | <10ms |
| | Anti-Sunlight/ strong light interference |
| | Touch Point | 2-48 optional |
| | Minimum identification point: | 3mm x 3mm |
| PC Info | CPU | Intel i3(i5,i7optional) |
| RAM | 4GB ,DDR3-1333, 8GB is optional |
| Hard Disk | 500GB |
| Graphics | Intel HD4000 |
| WIFI | 802.11 B.G.N |
| Audio card | Realtek ALC662 |
| Camera | Optional |
| OS | DOS, WINDOWS 7 or UP/ME/2000/ |
| XP/2003/VISTA, LINUX,MACOS,ANDROID. |
| Interfaces | VGA Output | 1 |
| HDMI Output | 1 |
| Audio Output | 1 |
| Microphone Input | 1 |
| USB | 4 or more depending on the main board |
| RJ45 | 1 |
| Accessory | Power supply cable, user manual, keys,adapter |
| Temperature Details:Touch screen working temperature:-41°C ~70°C, |
| Storage Temperature:-50°C ~85°C;The machine operating temperature:-4~65°C,Storage Temperature:-7~65°C. |
| Features |
| 1.Build-in High Quality speakers Stereo 2pcs x 5W. |
| 2.Build-in Mini-PC; It is optional for i3/i5/i7 . |
| 3.Adopts IR multipoint Touch Screen. |
| 4.Application fields:public places ,for example,shopping mall, restaurant,airport, square,commercial buildings,etc. |
| 5.Combined hardware and software solution for fast, reliable delivery of digital signage content and continuous operation. |
| 6.Easy WIFI network system installation without the need for extra IT, firewall or security configurations. |
