Parameter
Feature
1. OUTSTANDING VISIBILITY -- High Brightness
With a great brightness of 2000 cd/m², the display clearly delivers contents and attracts public attention, which is the ultimate display for outdoor visibility.
2. HIGH PERFORMANCE & RELIABILITY -- Smart Brightness Control
The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for effi cient power management.
3. HIGH PERFORMANCE & RELIABILITY -- Wide Operating Temperature Range
The panel offers superb reliability in a wide range of operating temperatures. The display can run normally in the work temprature from -40°C to +55°C.
4. HIGH PERFORMANCE & RELIABILITY -- Conformal Coating
Conformal Coating improves the long-term reliability of the main board and power board, protecting them from dust, iron powder, humidity, etc.
Because our products can be customized, we can provide more options as below.
1. Screen size from 10 to 100 inch
2. Installation way: Floor stand, wall mount, wall embedded, ceiling hanging or installing on a pole
3. OS: Android, windows, or stand-alone version
4. Touch screen (one-point touch or 10-point touch)
A. Infrared touch
B. Nano touch
C. Capacitive touch
5. Ingress Protection grade: IP55 to IP65
6. Color: Black, white, gray or other color you like.
7. If you need to change the configuration, like adding more peripheral equipment, such as OR scanner, receipt printer, web camera, light box, monochrome LED, etc., we can equip the digital signage with them, too.
More function can be added as below
CWD'S Certification
FAQ
Q1. What is your terms of packing?
A: Generally, we pack the goods neutrally (no brand name, no logo), however, if you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: 100% TT for sample ∣ 50% T/T, and 50% balance on delivery ready for bulk order.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU. Or according to your choices.
Q4. How about your delivery time?
A: It depends on the quantity as well as the date of order confirmation (by deposit). Generally our production time needs around 20 to 25 business days after confirming the drawing design. The time of goods leaving China to the destination address needs to be confirmed with freight forwarder.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can supply drawings according to the customization.
Q6. What is your sample policy?
A: We don't provide sample for free due to specialties of the products. Sample can be available if buyers pay the cost as well as freight. And the extra charge for sample will be refunded when bulk order comes.
Q7. Do you test all your goods before delivery?
A: Surely, that's an important way to make sure with quality. Our QC staffs will do their job very carefully. We will do the test, like watering test, waterproof test, radiation test, etc. Before delivery, we'll send you the testing results with sufficient videos and pictures.
Q8: What is your warranty policy?
A: 3 years (1 year for whole machine, 2 more years for hardware). Support in 48 hours.
PANEL | Panel Type | A+ TFT-LCD Panel 49 inch |
| Active Area | 604mm(Width)*1073mm(Height) | |
| Resolution | 1920*1080 FHD (Max to 3840*2160 UHD) | |
| Aspect Ratio | 16:9 | |
| Contrast Ratio | 1400:1 | |
| Displaying Color | 1.07B (8-bit + Dithering) | |
| View Angle | 178°(H) / 178°(V) | |
| Response Time | ≤ 5ms | |
| S-System | PAL / NTSC / SECAM | |
| Backlight | WLED | |
| Brightness | 2000 nits (Max to 3000 nits) | |
| Life Expectance | 60000 Hours | |
ENVIRONMENT | Cooling System | IP55 with Fan-cooling; IP65 with Air-conditioner |
| Work Temp | -20ºC to 55ºC | |
| Storage Temp | -25ºC to 60ºC | |
| Work/Storage Humidity | 10% to 90% | |
FUNCTION | Operating System | Android, 2G RAM; 8G ROM Windows, 4G RAM; 128G SSD ( I3, I5, I7 optional ) |
| Video Format | MP4,3GP,MPG,AVI,WMV,FLV,SWF,RMVB,MKV,VOB | |
| Image Format | JPG,BMP,PNG,TIF,ICO,GIF,TGA | |
| Audio Format | MP3,WMA,AMR,OGG,AAC,WAV,FLAC,APE | |
| Log Management | Supportive to terminal log and playlist log | |
| Power Mode | Time-setting On or Off | Manual | |
HARDWARE | Material | Galvanized steel sheet (1.5mm) with zinc powder coating and fine grain powder triple coating |
| Protective Glass | 6MM Laminated and Tempered glass | |
| I/O Interface | WIFI, 4G, USB, SD Card, HDMI | |
| Play Mode | Plug and play, Network(Remote) | |
| Peripheral Device | Camera, LED monochrome strip screen, Keyboard, Card reader, Speaker, Telephone, ReceiptPrinter, Finger-printer recognition, Bar code and OR code scanner ( optional ) | |
| Unit Carton Dimension | To be determined | |
| Unit G.W | To be determined | |
| Accessories | Remote Control, AC Power Cord, Key, Rack, Instruction, Approval Certificate, Warranty Card | |
| Certificates | ISO9001/CE/CCC/FCC/RoHS/IP65 | |
POWER | Voltage | AC 100V - 240V |
| Consumption | ≤250W | |
| Standby | ≤ 3W |
Feature
1. OUTSTANDING VISIBILITY -- High Brightness
With a great brightness of 2000 cd/m², the display clearly delivers contents and attracts public attention, which is the ultimate display for outdoor visibility.
2. HIGH PERFORMANCE & RELIABILITY -- Smart Brightness Control
The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for effi cient power management.
3. HIGH PERFORMANCE & RELIABILITY -- Wide Operating Temperature Range
The panel offers superb reliability in a wide range of operating temperatures. The display can run normally in the work temprature from -40°C to +55°C.
4. HIGH PERFORMANCE & RELIABILITY -- Conformal Coating
Conformal Coating improves the long-term reliability of the main board and power board, protecting them from dust, iron powder, humidity, etc.
Because our products can be customized, we can provide more options as below.
1. Screen size from 10 to 100 inch
2. Installation way: Floor stand, wall mount, wall embedded, ceiling hanging or installing on a pole
3. OS: Android, windows, or stand-alone version
4. Touch screen (one-point touch or 10-point touch)
A. Infrared touch
B. Nano touch
C. Capacitive touch
5. Ingress Protection grade: IP55 to IP65
6. Color: Black, white, gray or other color you like.
7. If you need to change the configuration, like adding more peripheral equipment, such as OR scanner, receipt printer, web camera, light box, monochrome LED, etc., we can equip the digital signage with them, too.
More function can be added as below
CWD'S Certification
FAQ
Q1. What is your terms of packing?
A: Generally, we pack the goods neutrally (no brand name, no logo), however, if you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: 100% TT for sample ∣ 50% T/T, and 50% balance on delivery ready for bulk order.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU. Or according to your choices.
Q4. How about your delivery time?
A: It depends on the quantity as well as the date of order confirmation (by deposit). Generally our production time needs around 20 to 25 business days after confirming the drawing design. The time of goods leaving China to the destination address needs to be confirmed with freight forwarder.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can supply drawings according to the customization.
Q6. What is your sample policy?
A: We don't provide sample for free due to specialties of the products. Sample can be available if buyers pay the cost as well as freight. And the extra charge for sample will be refunded when bulk order comes.
Q7. Do you test all your goods before delivery?
A: Surely, that's an important way to make sure with quality. Our QC staffs will do their job very carefully. We will do the test, like watering test, waterproof test, radiation test, etc. Before delivery, we'll send you the testing results with sufficient videos and pictures.
Q8: What is your warranty policy?
A: 3 years (1 year for whole machine, 2 more years for hardware). Support in 48 hours.
