Technical parameters

UNIT

parameters values

Pixel pitch

MM

4

Panel size

MM

L256*H128*T

Physical density

dot/M²

62500

Pixel configuration

R/G/B

1,1,1

Driving method

1 / 16 constant current scanning

LED Encapsulation

SMD

2121

Display resolution

DOTS

64X32=2048

Module weight

KG

0.18

Module port

HUB75

Module working voltage

VDC

5

Module consumption

W

≤16

Every square metre module

PCS

30

Maximum power

W/ M²

<500

Equilibrium brightness

CD/ M²

≥900

Working environment temperature

⁰C

-10~60

Working environment humidity

RH

10%~70%

Display working voltage

VAC

AC46~54HZ,220V±15%/110V±15%

Best viewing distance

≥4M

Lamp failure frequency

<0.0001

IP rating

The back IP40,The front IP50

Control method

Synchronous or asynchronous control
